APL 5L Oil and Gas Pipeline L290-L485 Pipeline Seamless Steel Pipe

API 5L Seamless pipeline

APL 5L Oil and Gas Pipeline L290-L485 Pipeline Seamless Steel Pipe

Line pipe is the oil, gas or water pumped out of the ground, through the line pipe to the oil and gas industry enterprises. Line pipe includes seamless and welded pipe two kinds, its pipe end has a flat end, with threaded end and socket end; its connection for the end of the welding, hoop connection, socket connection.

Email:

sales@imristeel.com

Phone:

+86 13646172523

Quote Now

Product Detail

Packaging & Delivery

Product Detail

Product Description
Product Name	APL 5L Oil and Gas Pipeline L290-L485 Pipeline Seamless Steel Pipe
Standard	GB/T 9711. API SPEC 5L. A106. A53
Grade	L210-L485 A B C X42-X70
Size	Outer Diameter	39-457mm
	Wall Thickness	3.5-60mm or customized
	Length	6-12m or customized
Surface Treatment	Hot rolled
Layer Tolerance	±1%
Shape	Round
Place of Origin	Inner Mongolia, China
Usage	Gas and Oil Transportation
End	Plain,beveled,cutting,threading.flange or customized
End Protector	Plastic pipe caps,iron protector or customized
Package	1.Bundling with steel strip. 2.Oiled and packing with plastic wrap 3.In bulk. 4.Packing in woven bags. 5.As customer’s requirement
Shipping	1.Length 2.Length>/=6.0 Meters,Loaded in 40 Feet Container
Payment	TT/LC
Delivery Time	Normally within 45 days and according to the quantity.

Chemistry Component

Steel Grade (Steel Name)	Mass Fraction, Based on Heat and Product Analyses a,g %
	C	Mn	P		S	V	Nb	Ti
	max b	max b	min	max	max	max	max	max
Seamless Pipe
L175 or A25	0.21	0.60	—	0.030	0.030	—	—	—
L175P or A25P	0.21	0.60	0.045	0.080	0.030	—	—	—
L210 or A	0.22	0.90	—	0.00	0.030	—	—	—
L245 or B	0.28	1.20	—	0.030	0.030	c,d	c,d	d
L290 or X42	0.28	1.30	—	0.030	0.030	d	d	d
L320 or X46	0.28	1.40	—	0.030	0.030	d	d	d
L360 or X52	0.28	1.40	—	0.030	0.030	d	d	d
L390 or X56	0.28	1.40	—	0.030	0.030	d	d	d
L415 or X60	0.28 e	1.40 e	—	0.030	0.030	f	f	f
L450 or X65	0.28 e	1.40 e	—	0.030	0.030	f	f	f
L485 or X70	0.28 e	1.40 e	—	0.030	0.030	f	f	f
Welded Pipe
L175 or A25	0.21	0.60	—	0.030	0.030	—	—	—
L175P or A25P	0.21	0.60	0.045	0.080	0.030	—	—	—
L210 or A	0.22	0.90	—	0.030	0.030	—	—	—
L245 or B	0.26	1.20	—	0.030	0.030	c,d	c,d	d
L290 or X42	0.26	1.30	—	0.030	0.030	d	d	d
L320 or X46	0.26	1.40	—	0.030	0.030	d	d	d
L360 or X52	0.26	1.40	—	0.030	0.030	d	d	d
L390 or X56	0.26	1.40	—	0.030	0.030	d	d	d
L415 or X60	0.26 e	1.40 e	—	0.030	0.030	f	f	f
L450 or X65	0.26 e	1.45 e	—	0.030	0.030	f	f	f
L485 or X70	0.26 e	1.65 e	—	0.030	0.030	f	f	f
a Cu ≤ 0.50 %; Ni ≤ 0.50 %; Cr ≤ 0.50 % and Mo ≤ 0.15 %. b For each reduction of 0.01 % below the specified maximum concentration for carbon, an increase of 0.05 % above the specified maximum concentration for Mn is permissible, up to a maximum of 1.65 % for grades ≥ L245 or B, but ≤ L360 or X52; up to a maximum of 1.75 % for grades > L360 or X52, but < L485 or X70; and up to a maximum of 2.00 % for Grade L485 or X70. c Unless otherwise agreed, Nb + V ≤ 0.06 %. d Nb + V + Ti ≤ 0.15 %. e Unless otherwise agreed. f Unless otherwise agreed, Nb + V + Ti ≤ 0.15 %. g No deliberate addition of B is permitted and the residual B ≤ 0.001 %.

Mechanical Performance

Standard	Product Level	Steel grade	Yield Strength (min),Mpa	Tensile Strength(MPa)
API5L GB/T9711	PSL 1	A or L210	210	335
		B or L245	245	415
		x42 or L290	290	415
		X46 or L320	320	435
		X52 or L360	360	460
		X56 or L390	390	490
		X60 or L415	415	520
		X70	483	565
	PSL2	BR or L245R	245~450	415~760
		X42R or L290R	290~495	415~760
		BN or L245N	245~450	415~760
		X42N or L290N	290~495	415~760
		X46N or L320N	320~525	435~760
		X52N or L360N	360~530	460~760
		X56N or L390N	390~545	490~760
		X60N or L415N	415~565	520~760
		X65N or L450N	425~566	525~760
		X70 or L480	484~565	565~768
		X80	552~690	621~827

Packaging & Delivery

· Packaging Details: Bundles wrapped with strong steel trips, caps on two ends of every pipe or according to customers’ requirements.
· Port: Tianjin Port
· Lead Time: Within 20-30 days depends on the order quantity

Packaging & Shipping

· Minimum order quantity: 5 tons
· Price: FOB or CIF or CFR at Xin’gang port in Tianjin
· Payment: 30% deposit in advance, the balance against the copy of B/L; or 100% L/C, etc
· Lead Time: within 10-25 workdays normally
· Packing: Standard seaworthy packing or as per your request .(as pictures)
· Sample: Free sample is available.
