U75V P65/R65 Rail GOST 51685 | 1520mm Broad Gauge Heavy Rail

Rail & Fittings, Steel Rail

U75V P65/R65 Rail GOST 51685 | 1520mm Broad Gauge Heavy Rail

P65/R65 rail manufactured with U75V steel grade is high-performance heavy rail designed for 1520mm broad-gauge railway systems in CIS and Central Asian markets, produced in accordance with GOST 51685 specifications.

Compared with conventional U71Mn rail, U75V features optimized chemical composition, superior wear resistance and enhanced fatigue performance. This grade is widely selected for lines bearing frequent heavy freight loads. With stable metallurgical structure and reliable welding performance, U75V P65/R65 rail effectively lowers track maintenance frequency and extends service life under continuous heavy cyclic load.

Email:

sales@imristeel.com

Phone:

+86 13646172523

Quote Now

Product Detail

Chemical Component

Standard & Dimension Table

Executive Standard: GOST 51685 Rail Type: P65 / R65 Heavy Steel Rail Applicable Gauge: 1520mm Broad Gauge

Parameter	Specification
Theoretical Weight	64.88 kg/m
Total Rail Height	180 mm
Rail Base Width	150 mm
Rail Head Width	73 mm
Web Thickness	18 mm
Flange Thickness	20.5 mm

Steel Grade Introduction — U75V

U75V is a vanadium microalloyed rail steel. The addition of vanadium refines grain structure, improving hardness, anti-fatigue capability and resistance to rolling contact fatigue.

Excellent wear resistance for heavy haul freight traffic
Strong resistance to rail head crack initiation
Stable performance under repeated heavy axle loads
Good adaptability for medium and low temperature environments
Optional rail head hardening treatment for further upgraded service life

Chemical Composition (GOST 51685)

Element	Content Range (%)
C (Carbon)	0.72 ~ 0.80
Si (Silicon)	0.60 ~ 0.90
Mn (Manganese)	0.75 ~ 1.05
P (Phosphorus)	≤ 0.030
S (Sulfur)	≤ 0.030
V (Vanadium)	0.02 ~ 0.08
Cr (Chromium)	≤ 0.15

Mechanical Properties (GOST 51685)

Mechanical Index	Standard Value (U75V)
Tensile Strength	≥ 920 MPa
Yield Strength	≥ 520 MPa
Elongation	≥ 9%
Rail Head Hardness	290 ~ 330 HB (Normal)350 ~ 390 HB (Head Hardened)
Low-temperature Impact Toughness	Reliable performance at -35℃

Application Scenarios

U75V P65/R65 heavy rail is preferred for medium & heavy-haul 1520mm broad-gauge railway projects:

Mining dedicated railways and long-distance industrial transport lines
Railway reconstruction & upgrading projects requiring long service cycle
Lines where frequent rail replacement and high maintenance costs need to be avoided
Heavy freight trunk lines in Uzbekistan, Kazakhstan, Russia and other CIS regions
Mixed traffic routes with high daily freight volume
