GB/T 8162-2018 20# Class Steel Tube Structure

GB/T 8162-2018 20# Class Steel Tube Structure

Manufacturers produce 20# structural seamless steel pipe in compliance with GB/T 8162 using carbon steel (equivalent to AISI 1020). This material offers a tensile strength of 410-550 MPa and demonstrates good machinability. These properties make it suitable for low/medium-pressure fluid transport, mechanical parts, and general structural applications, leading construction, machinery, and engineering sectors to widely adopt it for various projects.

Email:

sales@imristeel.com

Phone:

+86 13646172523

Quote Now
Product Detail
Chemical Component
Related Products

Quick Details

Product Name:
GB/T 8162-2018 20# Class Steel Tube Structure
Standard:
GB/T 8162-2018; GB/T 699-2015;GB/T 17395-2022
Grade:
20#
Thickness:
3-75mm
Section Shape:
Round
Outer Diameter:
32-630mm
Place of Origin:
Baotou, China(Mainland)
Usage:
Construction, Machinery, Engineering projects
Surface Treatment:
Hot Rolled
Tolerance:
OD: 32-50mm ±0.5mm; 50-630mm ±1.0%D WT: ≤3mm ±12.5%S; >3mm ±10%S
End:
Plain, beveled, or customized
End Protector:
Plastic pipe caps,iron protector or customized
length:
3-12m or customized
Brand:
Baotou steel
Delivery Time:
Normally within 30-45 days and according to the quantity.

Chemical Component(GB/T 8162)

GradeTypeCMnMoCrNiCuPSSi
MinMaxMinMaxMinMaxMinMaxMaxMaxMaxMaxMax
20#0.230.650.250.300.250.0350.0350.37

Mechanical Performance(GB/T 8162)

GradeTypeTotal under load

Elongation

%

Yield StrengthTensile StrengthHardnessSpecified

OD



mm

Allowable hardness

Variation

MinMaxMinHRCHBWHRC
20#25245410
