Delrin POM 100 NC010 Raw Material Injection Grade for Mechanical Parts

Others

Delrin POM 100 NC010 Raw Material Injection Grade for Mechanical Parts

DELRIN® 100NC010 is a high-performance acetal homopolymer (POM) developed by DuPont. Known for its exceptional mechanical strength, dimensional stability, and resistance to wear and chemicals, it is widely used in precision engineering applications requiring durability and reliability under demanding conditions.

Email:

sales@imristeel.com

Phone:

+86 13646172523

Quote Now

Product Detail

Packaging & Delivery

Product Detail

Product name:

POM DELRIN 100NCO1O

Place of Origin:

USA

Brand:

DUPONT

Model Number:

100NC010

Material:

Polyformaldehyde

Grade:

Injection Molding

Application:

Automobile, machine tool

Appearance:

Particles

Color:

White

Usage:

Gears, faucets

Alloy Or Not:

Sample:

Aviable

Supply Ability:

( 220.0000 )Ton/Tons per year

Package:

25kgs/bag

Specification:

POM

Brand:

Dupont

Technique:

Injection

Delivery time:

3-5 days

Test Requirements

ITEM	STANDARD	TEST RESULT
Melt Flow Rate @190C,2.16 (PERIODIC TEST)Kg,g/10min	ISO 1133	1.7	2.5	2.2
Notched Charpy Impact Str @23C kJ/m²	ISO 179/1eA	12.0	18.0	15.2
Tensile Modulus,Mpa	ISO 527-1&2	2800	3200	2955
Tensile Stress @Yield,50 mm/min,MPa	ISO 527	70	75	73

Key Properties

Mechanical Performance:

High stiffness, toughness, and creep resistance.

Excellent fatigue endurance for dynamic parts (e.g., gears, springs).

Low coefficient of friction, suitable for sliding/rotating components.

Thermal Stability:

Continuous service temperature: Up to 85°C (185°F).

Retains mechanical properties in sub-zero environments.

Chemical Resistance:

Resistant to hydrocarbons, alcohols, and many organic solvents.

Not recommended for strong acids, bases, or chlorine-rich environments.

Dimensional Stability:

Low moisture absorption (<0.2%), ensuring tight tolerances in humid conditions.

Machinability:

Easily machined into complex shapes with CNC or traditional tools.

Packaging & Delivery

(1)Packing : 25kg net/pp bag, or kraft paper bag .
(2) Loading quantity : 680Bags/20’container, 17MT/20’container .
(3) Loading quantity : 1000Bags/40’container, 25MT/40’container .

PS:
The resin should be stored in a drafty, dry warehouse and away from fire and direct sunlight.
During transportation, the material should not be exposed to strong sunlight or rain and should not be transported together with sand, soil, scrap metal, coal or glass. Transportation together with toxic, corrosive and flflammable substance is also prohibited strictly.

Packaging & Shipping

· Minimum order quantity: 5 tons
· Price: FOB or CIF or CFR at Xin’gang port in Tianjin
· Payment: 30% deposit in advance, the balance against the copy of B/L; or 100% L/C, etc
· Lead Time: within 7-10 workdays normally
· Packing: Standard seaworthy packing or as per your request .(as pictures)
· Sample: Free sample is available.
