GB/T 18248 30CrMo Gas Cylinder Tube

GB/T 18248 30CrMo Gas Cylinder Tube

GB/T 18248 30CrMo Gas Cylinder Tube

30CrMo Gas Cylinder Tube is a kind of alloy structural steel. Its quench-hardening ability is higher, no temper brittleness. This material demonstrates very low tendency for cold crack formation while maintaining excellent machinability and cold straining plasticity. These properties make 30CrMo ideally suited for manufacturing critical components including CNG/LPG/hydrogen storage tanks, firefighting breathing apparatus cylinders, medical oxygen cylinders, industrial gas cylinders, fuel cell vehicle hydrogen tanks, scuba diving tanks, as well as various aerospace and military applications.

Email:

sales@imristeel.com

Phone:

+86 13646172523

Quote Now
Product Detail
Chemical Component
Related Products

GB/T 18248 30CrMo Gas Cylinder Tube

GB/T 18248 30CrMo Gas Cylinder Tube

Product Detail

Product Name:
GB/T 18248 30CrMo Gas Cylinder Tube
Standard:
GB/T 18248 ,EN 10297,EN 10083-3
Grade:
30CrMo
Thickness:
4-18 mm
Section Shape:
Round
Outer Diameter:
89mm-368mm
Place of Origin:
Baotou, China(Mainland)
Usage:
LPG/CNG cylinders , Industrial gas storage ,Firefighting BA,Type I Hydrogen,Medical Oxygen,Lightweight/Vehicle H2
Surface Treatment:
Quenched and Tempered
Tolerance:
OD: ±1% WT: 0.9mm
End:
Plain,beveled,cutting,threading.flange or customized
End Protector:
Plastic caps Anti-corrosion coating
length:
4m-12m(customized)
Brand:
Baotou steel
Delivery Time:
Normally within 30-45 days and according to the quantity.

Chemical Component (GB/T 18248)

GradeCSiMnPSP+SCrMoNiCu
30CrMo0.26~0.330.17~0.370.40~0.70≤0.020≤0.010≤0.0250.80~1.100.15~0.25≤0.30≤0.20



Mechanical Performance (GB/T 18248)

GradeTensile strength RmYield strength YSElongation A(%)
30CrMo≥930MPa≥785MPa≥12
