API 5CT P110 Casing for Ultra-Deep Wells

Casing, Tubing & Casing Pipe

API 5CT P110 Casing for Ultra-Deep Wells

The API 5CT P110 casing provided by IMRI is a high-strength seamless oil well casing. It complies with the API 5CT standard, with a minimum yield strength of 758 MPa and a minimum tensile strength of 862 MPa. It provides the wellbore with robust structural integrity, effectively resisting external collapse pressures from rock formations and internal production. Its outstanding performance makes it an ideal choice for deep and ultra-deep well oil drilling and production.

Email:

sales@imristeel.com

Phone:

+86 13646172523

Quote Now

Product Detail

Chemical Component

Product Detail

Product Name:

API 5CT P110 Casing for Ultra-Deep Wells

Standard:

API 5CT / API 5B

Grade:

P110

Thickness:

3.5-60mm

Shape:

Round

Outer Diameter:

Ф114.3 – 406 mm

Place of Origin:

Inner Mongolia, China

Usage:

Structural Support; Wellbore Protection

Surface Treatment:

Hot Rolled

Tolerance:

WT: -12.5%

End:

Plain

End Protector:

HDPE crash cap or customized

length:

R1, R2, R3

Brand:

Baotou steel

Delivery Time:

Normally within 30-45 days and according to the quantity.

Chemical Component(API 5CT)

Grade

Min

Max

Min

Max

Min

Max

Min

Max

P110

一

0.030

一

Mechanical Property(API 5CT)

Grade

Type

Total under load

Elongation

Yield strength

megapascal

Tensile strength

megapascal

Hardness a, C

Maximum

Specified

Allowable hardness

Variation

Min

Max

Min

HRC

HBW

HRC

P110

–

0.6

758

965

862

–

Case:

IMRI’s P110 casing is widely used in oil and gas extraction in complex geological conditions such as deep wells, ultra-deep wells, and high-pressure gas wells due to its high strength and resistance to crushing. In China, P110 casing has been successfully applied in the Tarim Oilfield’s ultra-deep well project (depth exceeding 7,000 meters, with formation pressure exceeding 100 MPa). It is also used in the development of the Mukhaizna Oilfield in Oman, which is renowned for its complex conditions with high hydrogen sulfide content. These P110 casings can withstand the challenges of high temperatures, high pressures, and strongly corrosive media, ensuring stable production at the oilfield.
