API 5CT 13% Chromium L80 Tubing

IMRI’s L80-13Cr tubing manufactures in strict compliance with API 5CT standards, and its chemical composition is precisely formulate to effectively resist corrosive media such as CO₂and Cl-. It helps oil and gas fields to realize long-term stable production and improve economic benefits.

Email:

sales@imristeel.com

Phone:

+86 13646172523

Quote Now

Product Detail

Chemical Component

Product Detail

Product Name:

API 5CT 13% Chromium L80 Tubing

Standard:

API 5CT / API 5B

Grade:

L80-13Cr

Thickness:

3.5-60mm

Shape:

Round

Outer Diameter:

Ф 60.3-114.3 mm

Place of Origin:

Inner Mongolia, China

Usage:

Transportation of oil and gas

Surface Treatment:

Hot Rolled

Tolerance:

WT: -12.5%

End:

Plain

End Protector:

HDPE crash cap or customized

length:

R1, R2, R3

Brand:

Baotou steel

Delivery Time:

Normally within 30-45 days and according to the quantity.

Chemical Component(API 5CT)

Grade

Min

Max

Min

Max

Min

Max

Min

Max

L80-13Cr

0.15

0.22

0.25

1.00

一

12.0

14.0

0.50

0.25

0.020

0.010

1.00

Mechanical Property(API 5CT)

Grade

Total under load

Elongation

Yield strength

megapascal

Tensile strength

megapascal

Hardness a, C

Maximum

Specified

Allowable hardness

Variation

Min

Max

Min

HRC

HBW

HRC

L80

13Cr

0.5

552

655

23.0

241

–

Case:

L80-13Cr tubing is mainly used in sour oil and gas well environments and has been successfully applied in several ultra-deep well projects, significantly improving well productivity and safety while maintaining high strength and toughness, and becoming an important contributor to the full localization of the ‘Tarim Oilfield’. Participation in high mineralization gas lift system – Oman Mukhaizna oilfield Φ88.9mm tubing (mineralization 120,000mg/L corrosion rate <0.03mm/a).
