3PE anti-corrosion pipe is a kind of pipe product that strengthens the protection of steel pipe through three-layer composite coating technology. Its anti-corrosion layer is composed of FBE bottom layer, adhesive middle layer and high density polyethylene (HDPE) outer layer, forming a collaborative protection system with both chemical stability and physical resistance. Widely used in oil, natural gas, water and other fields of corrosive environment transportation engineering.
- Pipeline de revêtement, Revêtement à usage particulier
3PE Anti-corrosion Steel Pipe Epoxy Coating Reinforce Grade Gas Pipeline1
Email:
sales@imristeel.com
Phone:
+86 13646172523
Quote Now
Product Details
Packaging & Delivery
Produits connexes
Product Detail
(A brief introduction to the content) 3LPP welded pipe/3LPP seamless steel pipe, The three layers Polyethylene(3PE/3LPE) line pipe consists of a high-performance fusion-bonded epoxy(FBE) layer, an adhesive layer and an outer layer of high-density polyethylene. The three layers of external coating has excellent resistance to abrasion, wear, acid, alkali and cathodic disbanding, etc.
Quick Details
Standard:
API 5L A106 A53 GB/T9711
Grade:
A B C X42~X70 L210~L485
Thickness:
2.9-60mm
section shape:
Round
Outer Diameter:
Ф38-457
Place of origin:
Baotou, China(Mainland)
Application:
Structure Pipe
Technique:
Hot Rolled, Seamless
Certification:
API
Surface Treatmen:
According to customers request
Alloy Or Not:
No
length:
1-12m
Supply Ability:
( 180.0000 )Ton/Tons per year
End:
Bevel; plain
Specification:
steel pipe
Brand:
Baotou steel
Technique:
seamless
Finish:
Hot Rolled
Chemistry Component
| Grade | C | Mn | p | S | V | Nb | Ni | |
| Max. | Max.b | Min. | Max. | Max. | Max. | Max. | Max. | |
| L210 a | 0.22 | 0.9 | 0.03 | 0.03 | 0.03 | – | – | – |
| L245 b | 0.28 | 1.2 | 0.03 | 0.03 | 0.03 | c,d | c,d | c,d |
| L290 x42 | 0.28 | 1.3 | – | 0.03 | 0.03 | d | d | d |
| l320 x46 | 0.28 | 1.4 | – | 0.03 | 0.03 | d | d | d |
| L365 x52 | 0.28 | 1.4 | – | 0.03 | 0.03 | d | d | d |
| L390 x56 | 0.28 | 1.4 | – | 0.03 | 0.03 | d | d | d |
| L415 x60 | 0.28e | 1.40e | – | 0.03 | 0.03 | f | f | f |
| L450 x65 | 0.28e | 1.40e | – | 0.03 | 0.03 | f | f | f |
| L485 x70 | 0.28e | 1.40e | – | 0.03 | 0.03 | f | f | f |
Tensile test requirements
| Steel grade | Yield strength | Tensile strength | Elongation |
| Mpa(psi) | Mpa(psi) | （50mm or 2inn） | |
| L210 or A | 210（30500） | 335（48600） | c |
| L245 or B | 245（35500） | 415（60200） | c |
| L290 or X42 | 290（42100） | 415（60200） | c |
| L320 or X46 | 320（46400） | 435（63100） | c |
| L365 or X52 | 360（52200） | 460（66700） | c |
| L390 or X56 | 390（56600） | 490（71100） | c |
| L415 or X60 | 415（60200） | 520（75400） | c |
| L450 or X65 | 450（65300） | 535（77600） | c |
| L485 or X70 | 485（70300） | 570（82700） | c |
Packaging & Delivery
Packaging & Delivery
· Packaging Details: Bundles wrapped with strong steel trips, caps on two ends of every pipe or according to customers’ requirements.
· Port: Tianjin Port
· Lead Time: Within 20-30 days depends on the order quantity
· Port: Tianjin Port
· Lead Time: Within 20-30 days depends on the order quantity
Packaging & Shipping
· Minimum order quantity: 5 tons
· Price: FOB or CIF or CFR at Xin’gang port in Tianjin
· Payment: 30% deposit in advance, the balance against the copy of B/L; or 100% L/C, etc
· Lead Time: within 10-25 workdays normally
· Packing: Standard seaworthy packing or as per your request .(as pictures)
· Sample: Free sample is available.
· Price: FOB or CIF or CFR at Xin’gang port in Tianjin
· Payment: 30% deposit in advance, the balance against the copy of B/L; or 100% L/C, etc
· Lead Time: within 10-25 workdays normally
· Packing: Standard seaworthy packing or as per your request .(as pictures)
· Sample: Free sample is available.
